Quick Details

  • Condition: New
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: UNI-TECH
  • Model Number: XK715
  • Type: Universal
  • CNC or Not: CNC
  • Voltage: Customer Requirement
  • Power(W): 7.5kw
  • Dimension(L*W*H): 3650x2380x2750mm
  • Weight: 7300kgs
  • Certification: CE ISO9001
  • Warranty: 12 Months
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product name: XK715 CNC heavy duty bed-type universal milling machine
  • Model: XK715
  • Table size: 2100x500mm
  • Table travel: 1500x550mm
  • Longitudinal travel: 1500mm
  • Max.load of table: 2000kgs
  • Rapid feed speed: 6000mm/min
  • Spindle speed range: 35-1345rpm
  • Spindle motor power: 7.5kw
  • Machine weight: 7300kgs

Packaging & Delivery

Packaging Details Standard export ply/wcase package
Overall dimension: 3650x2380x2750mm
XK715 CNC heavy duty bed-type universal milling machine
Delivery Time 45 days

XK715 CNC heavy duty bed-type universal milling machine

Product Description

XK715 is a CNC heavy duty bed-type unversal milling machine with the ISO50 spindle, sells very well in many countries, with the following main features:

Main features:

1.Rigid grey cast-iron construction allows heavy work load

2.Universal milling head system "Huron" can be adjusted to various angles

3.Solid flat guiding guarantees stability at heavy milling

4.Complete with swivel arm and clearly arranged control panel

5.Inductive hardened and polished guidings

6.Stepless feed adjustments in all axis

7.Reinforced saddle in robust box construction

8.Precisely polished table, ideally positioned on wide saddle

9.Column and stand in solid box construction

10.GSK 25i CNC system.SIEMENS 828D or FANUC 0I MATE MD  CNC control system for your choice.

Main specification

Specification of our XK715 CNC heavy duty bed-type universal milling machine:

MODELUNITXK715
Table size(L×W)mm2100×500
T-slot (WIDTH×NO.)mm20×4
Max. travelLongitudinalmm1500
Crossmm600
Feed speed of Longitudinal and cross Speed rangemm/min 2.5~3000
Rapid feed speedmm/min 6000
Max load of tableKg2000
HEAD
Distance from spindle nose to table surfaceVertical spindlemm0~650
Distance from spindle axis to table surfaceHorizontal spindlemm8~660
Feed speed of Z axisSpeed rangemm/min 2.5~2500
Rapid feed speed of Zmm/min 3000
SPINDLE
Distance from spindle axis to column guidewaymm610
Spindle speedstep 12
Speed rangerpm35~1345
Spindle taperISO507:24
MOTOR
Spindle drive motorkw7.5
Feed motorkw (AC)2.5(Y,Z)
1.4(X)
Coolant pump motorw550
Lubricant pump motorw120
Overall sizemm3650×2380×2750
Machine weightkg7300



Standard accessoires :

1) Stepless longitudinal and cross feed

2) Work  light

3) Universal mill head

4) Horizontal counter bearing

5) Long milling arbor ISO 50 / 32 mm

6) Taper shell end mill holder ISO 50 / 40 mm

7) Telescope cover in z-axis

8) Universal protective device

9) Protective cover for horizontal milling

10) Central lubrication

11)Tools



Optional accessories:

The CNC 4th-axis (Rotary table or Universal Dividing head



Detailed Images

You could get more important informations from the following detailed pictures about XK715 CNC heavy duty bed-type universal milling machine:



Packaging & Shipping

XK715 CNC heavy duty bed-type universal milling machine

XK715 is a CNC milling machine, it can’t be packed separately.

Packing size: 228*256*286cm   7300/8000KG



Our Services

We will supply the following documents after the shipment:

1)    Bill of Lading

2)    Commercial invoice

3)    Packing list

4)    FTA  Certificate

5)    One paper catalogue of our company

We also would like to let you know our warranty about our XK715 CNC heavy duty bed-type universal milling machine as following:



What about the spare part if the machine break down?
==about the machine break down, normally our policy will be as the under way
   1) Our quality guarantee time is 12 months since the machine on board
   2) During this period, if the machine break down owing our machine itself quality problem,  we will prepare the spare parts and send to you by free within 5 days. all these will be by free.
  3) If the break down is caused by the mis operation,  we of course will supply you the spare parts, but we have to charge you the costs prices.
