SGA2550AHD Hydraulic Automatic surface grinder machine

FOB Reference Price:Get Latest Price
$5,100.00 - $9,800.00 / Sets | 1 Set/Sets SGA2550AHD Hydraulic Automatic surface grinder machine (Min. Order)
Model Number:
SGA2550AHD
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 60 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Surface Grinding Machine
CNC or Not:
Normal
Max. Grinding Diameter:
450mm
Max. Grinding Length:
560mm
Place of Origin:
Shandong, China
Brand Name:
UNI-TECH
Voltage:
220V/380V/415V
Power(W):
2200w
Dimension(L*W*H):
2000x2100x2175mm
Certification:
CE ISO9001
Name:
SGA2550AHD Hydraulic Automatic surface grinder machine
Model:
SGA2550AHD
Table size:
250x500mm
Table travel:
275*560mm
Max.distance spindle center to table:
450mm
Electro magnetic chuck size:
250*500mm
Spindle motor:
2.2kw
Rapid speed:
990mm
Max.loading capacity of table:
180kg
Feed of handwheel:
0.02mm/div
After-sales Service Provided:
Engineers available to service machinery overseas
Weight:
1800kg
Supply Ability
Supply Ability:
20 Set/Sets per Month SGA2550AHD Hydraulic Automatic surface grinder machine
Packaging & Delivery
Packaging Details
Standard export pallet package
SGA2550AHD Hydraulic Automatic surface grinder machine
Port
Qingdao,Shanghai,China
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 60 To be negotiated

SGA2550AHD Hydraulic Automatic surface grinder machine

Product Description

Feature:

1.For SGA2550AHD Hydraulic Automatic surface grinder machine, Plastic-coated counter guide in x- and y-axis assure a low slip-stick-effect

2.V-flat longitudinal table guide, double-V cross table guide

3.Spindle features axial and radial, clearance-free, pre-tensioned bearings

4.Seperate hydraulic unit with heat exchanger to omit vibrations and thermal load

5.Special hydraulic system guarantees gentle table adjustment even at full load

6.Solidly constructed and well supported structure assures high stability

7.SGA2550AHD Hydraulic Automatic surface grinder with Digitally controlled, automatic vertical feed with servo motor

8.Infeed via rapid feed to height of workpiece, adjustable to finishing and sparking, automatic lift at program end

9.Adjustable longitudinal and cross table movement via end stops



Our SGA2550AHD Hydraulic Automatic surface grinder machine with the different models for your choice:

AH series:   Auto cross feed; Hydraulic longitudinal feed; Manual vertical feed

AHR series:   Auto cross feed; Hydraulic longitudinal feed; Rapid vertical feed

AHD series:   Auto cross feed;  Hydraulic longitudinal feed; Automatic vertical feed

Main specification

SGA2550AHD Hydraulic Automatic surface grinder machine:



MODELUnitSG2050AHSGA2550AH
SG2050AHRSGA2550AHR
SG2050AHDSGA2550AHD
Table size(W x L)mm200x460250x500
Max longitudinal travelmm510560
Max cross travelmm238275
Max distance from spindle center to tablemm450450
Electro magnetic chuck sizemm200x460250x500
Speed of table longitudinal movementm/min5~25
Table transverse movementAuto feedmm/min0.1-8
Rapid speedmm/min990
Feed of handwheelMm/div0.02
Wheelhead vertical movementAuto feedmm(H/AH/AHR model)/0.005/0.01/0.02/0.03/0.04/0.05(Only for AHD model)
Rapid speedMm/min(H/AH model)  /460(for AHR model)
Feed of handwheelMm/div0.005
GrindingSpeedrpm2850(50Hz)  3450(60Hz)
wheel
 Sizemm200x20x31.75
Spindle motorkw1.52.2
Hydraulic motorkw0.75
Cooling pump motorkw0.04
Elevating motorkw(AH mode)  0.25(AHR mode)  0.5(AHD mode, servo motor)
Cross feed motorkw0.04
Max loading capacity of tableKg120180
Total rated powerkw333.7
Height of machinemm1675
Floor space(LxW)mm2050x14002300x1600
Gross weightkg16001800
Package dimensions(L x W x H)mm1900x1720x21752000x2100x2175
Detailed Images

Standard accessories:

Wheel flange

Balancing arbor

Wheel exactor

Coolant tank

Working lamp

Tool box and tools

Wheel dresser stand not include diamond pen,

Standard grinding wheel

Leveling wedge and bolt

Standard electro magnetic chuck

Built in electro magnetic chuck controller

PLC(AHD)\PLC auto grinding controller only for AHD models

Y-AXIS WITH STEP MOTOR,

Z—AXIS WITH SERVE MOTOR



Optional accessories:

Electric Magnetic chuck

Balance stand

Wheel flange

Coolant with magnetic separator and paper filter

Parallel wheel dresser screw rod type

Our Services

We also would like to let you know our warranty about our SGA2550AHD Hydraulic Automatic surface grinder machine as following:

What about the spare part if the machine break down?
==about the machine break down, normally our policy will be as the under way
   1) Our quality guarantee time is 12 months since the machine on board
   2) During this period, if the machine break down owing our machine itself quality problem,  we will prepare the spare parts and send to you by free within 5 days. all these will be by free.
  3) If the break down is caused by the mis operation,  we of course will supply you the spare parts, but we have to charge you the costs prices.



Packaging & Shipping

SGA2550AHD Hydraulic Automatic surface grinder machine

Standard export pallet package

Company Information

TENGZHOU UNI-TECH CO.,LTD was established in 2010.We are professional machine export in China. Our main products is grinding machine, turret milling machine.We have own quality control engineers and established quality control system to assure the customers’ requirements. The machines are widely exported to more than 90 countries & regions,including U.S.A.,Canada,Germany,Italy,Spain,G.B.,France,Turkey,Australia,Korea and so on,especially Europe & America cover the main part of the market.
We would like to establish long-term business-relations with customers all over world on the basis of sincere-cooperation, equality and mutual benefit. Good quality, competitive price, and satisfying service are our promises as a reliable trading partner.

FAQ



Contact us!

 Welcome come to contact us to get more details!

Canthy Guo

Tengzhou Uni-tech Co. Ltd
Tel:0632-5810216
Skype: live:canthyguo
Whatsapp: +8618266249928
