CS6266C CS series 2000mm bed length metal lathe

FOB Reference Price:Get Latest Price
$4,100.00 - $14,000.00 / Sets | 1 Set/Sets CS6266C CS series 2000mm bed length metal lathe machine (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Horizontal, CS series 2000mm bed length metal lathe machine
CNC or Not:
Normal
Automatic Grade:
Manual
Place of Origin:
Shandong, China
Brand Name:
UNI-TECH
Model Number:
CS6266Cx2000
Voltage:
220V/380V/415V
Dimension(L*W*H):
3200x1150x1880mm
Certification:
ISO9001
Name:
CS6266C CS series 2000mm bed length metal lathe
Model:
CS6266C
Max.swing over bed:
660mm
Spindle bore:
105mm
Max.swing over cross slide:
420mm
Max.distance between centers:
2000mm
Tool section:
25x25mm
Main motor:
7.5kw
Spindle speed:
12 steps 36-1600rpm
Weight:
3200kg
After-sales Service Provided:
Engineers available to service machinery overseas
Power(W):
7.5kw
Max. Swing Diameter:
500mm
Supply Ability
Supply Ability:
120 Set/Sets per Month CS6266C CS series 2000mm bed length metal lathe machine
Packaging & Delivery
Packaging Details
CS6266C CS series 2000mm bed length metal lathe
Packing size: 3200x1150x1880mm
Packed in plyw/case
Port
Shanghai,Qingdao,other port of China
Lead Time :
30 days after receive deposit

CS6266C CS series 2000mm bed length metal lathe

Product Description

CS6266 is the precision horizontal metal lathe machine with spindle bore diameter 52mm.

CS6266B is the precision horizontal metal lathe machine with spindle bore diameter 82mm.

CS6266C is the precision horizontal  metal lathe machine with spindle bore diameter 105mm.

Different distance between centers: 750/1000/1500/2000/3000mm

You can choose the suitable model turning lathe machine you need.

Main features:

1)CS6266C CS series 2000mm bed length metal lathe machine Can perform internal and external turning, taper turning, end facing, and other rotary parts turning;

2) Threading Inch, Metric, Module and D.P.;

3) CS6266C CS series 2000mm bed length metal lathe machine Perform drilling, boring and groove broaching;

4) CS6266C CS series 2000mm bed length metal lathe machine can Machine all kinds of flat stocks and those in irregular shapes;

5) Respectively with through-hole spindle bore, that can hold bar stocks in larger diameters;

6) Both Inch and Metric system are used on these series lathes, it's easy for people from different measuring systems countries;

7) There are hand brake and foot brake for users to choose for CS6266C CS series 2000mm bed length metal lathe machineCS6266C CS series 2000mm bed length metal lathe machine.

8) These series lathes operate on power supply of different voltages (220V,380V,420V) and different frequencies (50Hz,60Hz).



Main specification

Specification:



CS series 2000mm bed length metal lathe machineUnitParameter
CS6266C
CapacityMax swing over bedmmΦ660
Max swing in gapmmΦ870
Effective length in gapmm240
Max swing over slidemmΦ420
Max workpiece lengthmm1000/1500/2000/3000
SpindleSpindle thru-holemmΦ105
Spindle nose  ISO 702/Ⅱ No.8 cam-lock type
Spindle speedr/min12 step 36-1600
Spindle motorkW7.5
TailstockQuill dia./travelmmφ75/150
Taper of centerMT5
Tool postNumber of station/ 4/25x25
Tool section
FeedMax X-axis travelmm145
Max Z-axis travelm/min320
X-axis feedmm/r65 kinds 0.027-1.07
Z-axis feed Z-axis feedmm/r65 kinds 0.63-2.52
Metric threadmm22 kinds 1-14
Inch threadt.p.i25 kinds 28-2
Module threadπmm18 kinds 0.5-7
DP threadt.p.i. π24 kinds 56-4
OthersCoolant pump motorkW0.12
Packing sizemm2800x1150x1880 2800/3250
Net weight/Gross weight(1000mm)kg
Packing sizemm3000x1150x1880
Net weight/Gross weight(1500mm)kg3000/3475
Packing sizemm3200x1150x1880
Net weight/Gross weight(2000mm)kg3200/3680
Packing sizemm4800x1150x1880
Net weight/Gross weight(3000mm)kg3500/4100



Standard accessories:

3-jaw chuck, 4-jaw chuck, steady rest, follow rest,

face plate, drive plate, change gear set, reduction sleeve,

chasing dial indicator,full length splash guard,

tool box and tools, coolant system, brake system,

work lamp, dead center, Siemens electric, English manual.



Optional accessories:

SINO 2-axis Digital readout

Quick change toolpost

Live center

Turning tools

Safety protection guard (Leadscrew guard/Chuck guard/Tool post guard)

Packaging & Shipping

CS6266C CS series 2000mm bed length metal lathe machine

Packing size: 3200x1150x1880mm

Packed in plyw/case

Our Services

We also would like to let you know our warranty about our CS6266C CS series 2000mm bed length metal lathe machine.

What about the spare part if the machine break down?
==about the machine break down, normally our policy will be as the under way
   1) Our quality guarantee time is 12 months since the machine on board
   2) During this period, if the machine break down owing our machine itself quality problem,  we will prepare the spare parts and send to you by free within 5 days. all these will be by free.
  3) If the break down is caused by the mis operation,  we of course will supply you the spare parts, but we have to charge you the costs prices.

Company Information

 TENGZHOU UNI-TECH CO.,LTD have more than 20 years export experience, our CS6266C CS series 2000mm bed length metal lathe machine with the good quality and best price, export to more than 50 countries, and get the good feedback from all our customers for our this kind of lathe machine.

FAQ



Contact us!

 Welcome come to contact us to get more details!

Canthy Guo

Tengzhou Uni-tech Co. Ltd
Tel:0632-5810216
Skype: live:canthyguo
Ph/Wechat: +8618266249928
